Ingénia Modular Air Handling Solutions

Ingénia’s modular air handlers give the designer unlimited capabilities within a pre-engineered air handler platform. The lean and versatile manufacturing process yields cost-effective air handlers with the same features and options typically found in fully custom air handlers. Our systems provide impeccable air quality while ensuring the comfort of occupants. Moreover, advances antimicrobial powder coating applied to all of the AHU’s interior surfaces and bacteria defeating UV lights are just a few examples of Ingénia’s options to prevent contamination and produce a healthier living environment.

Features and Benefits

Highest quality indoor and outdoor air handlers with unparalleled performances.

Pre-configured unit sizes with the ability to further modify cabinet dimensions with the Designer software, giving flexibility to match existing unit dimensions in retrofit applications. Output files can be PDF, Autodesk® AutoCAD® ou Autodesk® Revit®.

Units can be built in all galvanized steel, aluminum, all stainless steel or a combination of these materials.

The highest energy efficient air handler in the industry with complete no-through metal construction on all base frames, floors, walls, door and roof panels.

Polyurethane foam injected panels with R-values ranging from 13 to 26 depending on wall thicknesses.

Exterior and/or interior can be finished with an electrostatic powder coating, whereby all parts are coated before assembly to a minimum salt spray resistance of 10,000 hours.

Electrostatic antimicrobial powder coating for interior liners is available to meet the requirements of specialty markets such as healthcare, pharmaceutical and others. Minimum resistance to salt spray of 10,000 hours.

Complete interior wash-down option with water containment floors for healthcare, industrial and food processing applications. Floor drains available in all sections.

Inlet, discharge and radiated acoustical performances can be predicted with Ingénia's acoustic software.

Capacity and Performance

1000 to 200,000 CFM units to meet our customers needs.

Casing acoustical performances are tested by an accredited independent laboratory. Sound transmission values conform explicitly with the ASTM designations E90-85 and E413-73. Sound absorption values conform explicitly with the requirements of the ASTM standard: ASTM C423-84A and E795-90.

Cabinet pressure resistance is rated and tested up to positive and/or negative 12” w.g.

Air leakage rate is tested to less than 0.5% at the rated cabinet pressure up to 12” w.g.

Low noise NC-30 or NC-40 design. Acoustical performances can be enhanced with the use of Ingenia's acoustical absorption panel systems.

Wall deflection less than 1/240 at the rated cabinet pressure.

Exceptional uniform wall thermal resistance, R-value = 6.5/inch thickness.

Cabinets meet and exceed the AHRI standard 1350
Casing deflection rating class CD₁
Casing air leakage rating class CL₁
Casing thermal transmittance rating class CT₁
Casing thermal bridging rating class CB₀

Equipment and Design Options

Cabinet

Available wall thicknesses: 2”, 2.5”, 3” and 4”
Polyurethane foam injected insulation
Complete no-through metal on all base frames, floors, walls, doors and roof panels
Indoor and outdoor configuration available
Galvanized steel, aluminum, 304 or 316 stainless steel construction or a combination of these materials
Exterior and/or interior powder coating
Complete internal antimicrobial powder coating including all internal wall surfaces, filter racks, coil racks and all structural components
Outdoor vestibules: full or partial length
Roof curbs

Roof curbs

Chilled water and direct expansion coils
Direct and indirect evaporative cooling
Non-mechanical economizer cycles

Fans & Motors

Single or multiple EC (electronically commutated) fans
DWDI or PLENUM SWSI fans
AC, PM (permanent magnet) or EC motors
Variable frequency drives or control packages for EC motors

Heating

Hot water and steam coils
Integral face and bypass coils
Indirect and direct gas fired equipment
Open and closed element electrical heaters

Humidification

Humidification options consist of steam, spray, media and evaporative

Energy Recovery

Sensible or enthalpy energy recovery wheels
Sensible and total heat recovery plate exchangers
Refrigerant heat pipe systems
Run around loop systems

Dehumidification

Passive dehumidification with the use of a desiccant wheel or active with desiccant wheels and regenerative heat source

Filtration

Filter frames designed for high rigidity with easy-to-install bolted filter retainer clips
All filter efficiencies including HEPA and bio-containment filtration

Controls

Factory designed, provided and installed
Provided by temperature controls contractor and factory installed

Sound Attenuation

Media type silencer with DuPont™ Tedlar® lining
Specially designed acoustical baffles to achieve ultra-low airborne sound performance

Electrical and Wiring

Fluorescent or LED lights
UV lights
Complete wiring per voltage or single voltage with step down transformers
Rigid galvanized EMT conduits, threaded galvanized or aluminum conduits
Flexible liquid tight conduits
Factory mounted and wired frequency drives
Factory mounted, wired and programmed EC motor controllers
Power panels

Hydronic Piping

Factory provided and installed hydronic circuits

Quality Standards

AFBMA 9 Load ratings and fatigue life for ball bearings
AMCA 203 Field performance measurements
AMCA 210 Laboratory methods of testing fans for rating purposes
AMCA 300 Test code for sound rating air moving devices
AMCA 500 Test methods for louvers, dampers and shutters
ARI 410 Forced-circulation air cooling and air heating coils
ASHRAE 62-89 ventilation for acceptable indoor air quality
ASTM A525 Steel sheet, zinc coated by hot-dip process
ASTM E90-09 Standard for measurement of airborne sound transmission loss
NEMA MG1 National electrical manufacturers association (motors and generators)
NFPA 70 National fire protection code
NFPA 90A Installation of air conditioning and ventilation systems
OSHA Occupational safety and health administration
SMACNA HVAC metal duct association
UL 1995 Heating and cooling equipment

Certifications

Click/Tap here to close

Ingénia Custom Air Handling Solutions

Ingenias custom air handlers give the designer the broadest portfolio of options in the industry to provide solutions to the most unique situations. Ingenia air handlers can be configured to fit the most challenging spaces and difficult installations. Whether your need is related to a limited footprint, acoustics, specialized ventilation-monitoring capabilities or humidity control, we can design and build your air handler to your exact specifications. Ingenia’s custom air handling units are fully integrated systems that offer the same premium features as the Ingenia Modular AHU’s plus:

Air or water cooled DX A/C
Water source heat pumps
Indirect or direct fired gas heaters
Steam, hot water or electrical heat
Heat recovery with heat recovery wheel, flat plates or heat pipes
Hydronic piping manifolds or complete hydronic piping networks
Single or multi-point power connections
Programmable microprocessor controls

}

Features and Benefits

Infinitely variable cabinet dimensions, ideal flexibility to match serve our client’s needs.
